Content
[Stand-alone] No need to connect a computer or monitor
[Humanized operation] large 4x16 blue LED display, see more easily
[Slim design] 4cm body makes it easy to carry around
[Large frequency bandwidth] 4 x 480Mbps independent bandwidth parallel
[Strict compare] bit-to-bit comparison method to ensure that the data of sub-disk and source disk is completely consistent.
[Quick Format] Instant insertion of asynchronous formatting function, batch operation is more convenient
[H5 test] professional detection of bad blocks to determine the size of bad blocks, so that the true capacity of flash card has nothing to do
[Rate Test] Quickly detect the read/write speed of the card, and at the same time, it can automatically prompt according to the set criteria to achieve sorting and screening.
[Support common partition format] can automatically identify FAT, FAT32, exFAT, NTFS, ext2/3/4 partitions, direct copy of data
[Large-capacity copy] supports up to 2TB of TF card, USB flash drive and USB storage device
[Highly compatibility] Compatible with various chips, support format mainstream TF card / USB device, specifications automatically determine, no need to set
[Flash Devices Compatible] Support TF (microSD/microSDHC) card/USB2.0 (compatible with 1.1/3.0) devices
[Software Upgrade] Use TF card/USB disk to update F/W firmware directly, easily upgrade product
[Dual language support] The menu should be available in two languages, english and chinese
Function
Model : M316U
Operating Type : Standalone
Target : 15
Buffer Memory : 128MB
Asynchronous Mode : Yes
Smart Copy : Yes
Auto Counter : Yes
File System Supported : FAT16,FAT32,FAT32,NTFS,Ext2/3/4
Max Size Supported : 2TB
Language Support : English, Chinese
Display : 16 x 4 Blue LCD
Status LED : Green/Red LED on each port
Color : Silver
Maximum Read Speed : up to 10MB/Sec≈600MB/Min
Maximum Write Speed : up to 8 MB/Sec≈500MB/Min
Device Supported : Recognized USB 3.0/2.0/1.1 Flash Drives
Firmware Upgradeable : Yes
Power Supply Input : DC 12V（or 5V ）Adapter
Operating Humidity : 0% ~ 80%
Temperature Extremes : 40°C (104°F) / 5°C (41°F)
